Testing AWS SQS and Kinesis with JMeter + LocalStack

Run Your Entire AWS Test Environment Locally — Zero Cloud Costs

What Is LocalStack?

LocalStack is an open-source tool that emulates AWS cloud services entirely on your local machine. Instead of making real API calls to AWS, your applications and tests hit a local endpoint (http://localhost:4566) that behaves just like AWS.

Think of it as a mock AWS environment running in Docker — fully offline, completely free, and incredibly fast for development and testing.

Why Use LocalStack for JMeter Testing?

Benefit	Real AWS	LocalStack
Cost	Paid per request	Free
Setup time	Minutes	Seconds
Internet required	Yes	No
Data privacy	Cloud-stored	Fully local
CI/CD friendly	Requires credentials	No credentials needed
Speed	Network latency	Near-zero latency
Realistic throttling	Yes	Configurable

LocalStack is ideal for:

Development and unit testing
CI/CD pipeline validation
Demos and workshops
Exploratory testing without AWS costs

It’s not ideal for:

Final production load benchmarks (use real AWS for that)
Testing actual AWS throttling behavior
Multi-region scenarios

Step 1: Install LocalStack

Prerequisites

Docker installed and running — https://www.docker.com/
Python 3.7+ (for the LocalStack CLI)
AWS CLI installed (used to interact with LocalStack)

Option A: Install via pip (Recommended)

pip install localstack
pip install awscli-local  # LocalStack-aware AWS CLI wrapper

Verify installation:

localstack --version
awslocal --version

Option B: Run Directly via Docker

No installation needed — just pull and run:

docker run --rm -it \
  -p 4566:4566 \
  -p 4510-4559:4510-4559 \
  localstack/localstack

Option C: Docker Compose (Best for Teams)

Create a docker-compose.yml file:

version: "3.8"

services:
  localstack:
    container_name: localstack
    image: localstack/localstack:latest
    ports:
      - "127.0.0.1:4566:4566"
      - "127.0.0.1:4510-4559:4510-4559"
    environment:
      - SERVICES=sqs,kinesis
      - DEFAULT_REGION=us-east-1
      - DEBUG=1
      - DATA_DIR=/tmp/localstack/data
    volumes:
      - "./localstack-data:/tmp/localstack/data"
      - "/var/run/docker.sock:/var/run/docker.sock"

Start it:

docker-compose up -d

Check it’s running:

curl http://localhost:4566/_localstack/health

You should see:

{
  "services": {
    "sqs": "running",
    "kinesis": "running"
  },
  "version": "x.x.x"
}

Step 2: Configure AWS CLI for LocalStack

LocalStack accepts any fake credentials — it doesn’t validate them. Configure a dedicated profile:

aws configure --profile localstack

Enter these values:

AWS Access Key ID:     test
AWS Secret Access Key: test
Default region name:   us-east-1
Default output format: json

From now on, use --profile localstack --endpoint-url http://localhost:4566 with every CLI command.

Or use awslocal (the LocalStack CLI wrapper) which does this automatically:

awslocal sqs list-queues
awslocal kinesis list-streams

Step 3: Create SQS and Kinesis Resources Locally

Create SQS Queue

# Standard queue
awslocal sqs create-queue --queue-name jmeter-local-queue

# FIFO queue
awslocal sqs create-queue \
  --queue-name jmeter-local-queue.fifo \
  --attributes FifoQueue=true,ContentBasedDeduplication=true

Get the queue URL:

awslocal sqs get-queue-url --queue-name jmeter-local-queue

Output:

{
  "QueueUrl": "http://localhost:4566/000000000000/jmeter-local-queue"
}

Create Kinesis Stream

awslocal kinesis create-stream \
  --stream-name jmeter-local-stream \
  --shard-count 2

# Verify it's active
awslocal kinesis describe-stream \
  --stream-name jmeter-local-stream \
  --query 'StreamDescription.StreamStatus'

Step 4: Configure JMeter to Point to LocalStack

This is the key step — you need to tell the JMeter AWS plugin to use LocalStack’s endpoint instead of real AWS.

4.1 — Update User Defined Variables

In your JMeter test plan, update the User Defined Variables config:

Variable	Real AWS Value	LocalStack Value
`AWS_ACCESS_KEY`	Your real key	`test`
`AWS_SECRET_KEY`	Your real secret	`test`
`AWS_REGION`	`us-east-1`	`us-east-1`
`AWS_ENDPOINT_URL`	(empty)	`http://localhost:4566`
`SQS_QUEUE_URL`	Real SQS URL	`http://localhost:4566/000000000000/jmeter-local-queue`
`KINESIS_STREAM`	Real stream name	`jmeter-local-stream`

4.2 — Configure the Plugin Endpoint

Most AWS JMeter plugins have an Endpoint URL or Custom Endpoint field in the sampler. Set it to:

http://localhost:4566

If your plugin doesn’t have a GUI field for the endpoint, you can configure it via the AWS SDK system property in JMeter’s startup:

Edit bin/jmeter (Linux/Mac) or bin/jmeter.bat (Windows) and add:

JVM_ARGS="-Daws.sqs.endpoint=http://localhost:4566 \
           -Daws.kinesis.endpoint=http://localhost:4566"

Or pass it at startup:

./bin/jmeter \
  -Daws.sqs.endpoint=http://localhost:4566 \
  -Daws.kinesis.endpoint=http://localhost:4566

4.3 — Using JSR223 Sampler with LocalStack Endpoint

If you’re using Groovy scripts alongside the plugin, configure the endpoint override explicitly:

import software.amazon.awssdk.services.sqs.SqsClient
import software.amazon.awssdk.regions.Region
import java.net.URI

def sqsClient = SqsClient.builder()
    .region(Region.US_EAST_1)
    .endpointOverride(new URI("http://localhost:4566"))
    .credentialsProvider(
        software.amazon.awssdk.auth.credentials.StaticCredentialsProvider.create(
            software.amazon.awssdk.auth.credentials.AwsBasicCredentials.create("test", "test")
        )
    )
    .build()

Same pattern for Kinesis:

import software.amazon.awssdk.services.kinesis.KinesisClient
import software.amazon.awssdk.regions.Region
import java.net.URI

def kinesisClient = KinesisClient.builder()
    .region(Region.US_EAST_1)
    .endpointOverride(new URI("http://localhost:4566"))
    .credentialsProvider(
        software.amazon.awssdk.auth.credentials.StaticCredentialsProvider.create(
            software.amazon.awssdk.auth.credentials.AwsBasicCredentials.create("test", "test")
        )
    )
    .build()

Step 5: Run the SQS Test Against LocalStack

With LocalStack running and JMeter configured, your test plan is identical to the real AWS version — just pointing at localhost:4566.

Verify Messages Are Being Sent

After running your JMeter test, check the queue via CLI:

# Check queue depth
awslocal sqs get-queue-attributes \
  --queue-url http://localhost:4566/000000000000/jmeter-local-queue \
  --attribute-names ApproximateNumberOfMessages

# Receive a sample message manually
awslocal sqs receive-message \
  --queue-url http://localhost:4566/000000000000/jmeter-local-queue \
  --max-number-of-messages 1

Expected output:

{
  "Messages": [
    {
      "MessageId": "abc123...",
      "Body": "{\"eventType\":\"order_placed\",\"orderId\":\"uuid...\"}",
      "ReceiptHandle": "..."
    }
  ]
}

Step 6: Run the Kinesis Test Against LocalStack

Verify Records Are Ingested

# Get shard iterator
SHARD_ITERATOR=$(awslocal kinesis get-shard-iterator \
  --stream-name jmeter-local-stream \
  --shard-id shardId-000000000000 \
  --shard-iterator-type TRIM_HORIZON \
  --query 'ShardIterator' --output text)

# Read records
awslocal kinesis get-records \
  --shard-iterator $SHARD_ITERATOR \
  --limit 5

You should see your JMeter-generated records in the output.

Step 7: Automate with a LocalStack Init Script

For CI/CD or team setups, automate resource creation with an init script that runs when LocalStack starts.

Create localstack-init/init-aws.sh:

#!/bin/bash

echo "🚀 Initializing LocalStack resources..."

# Create SQS queues
awslocal sqs create-queue --queue-name jmeter-local-queue
awslocal sqs create-queue \
  --queue-name jmeter-local-queue.fifo \
  --attributes FifoQueue=true,ContentBasedDeduplication=true

# Create Kinesis streams
awslocal kinesis create-stream \
  --stream-name jmeter-local-stream \
  --shard-count 2

echo "✅ LocalStack resources ready!"

Update docker-compose.yml to run it on startup:

services:
  localstack:
    image: localstack/localstack:latest
    ports:
      - "127.0.0.1:4566:4566"
    environment:
      - SERVICES=sqs,kinesis
      - DEFAULT_REGION=us-east-1
    volumes:
      - "./localstack-init:/etc/localstack/init/ready.d"
      - "/var/run/docker.sock:/var/run/docker.sock"

Now every time LocalStack starts, your SQS queues and Kinesis streams are automatically created — no manual setup needed.

Step 8: Integrate LocalStack + JMeter in CI/CD

This is where LocalStack truly shines. Run your entire AWS messaging test suite in GitHub Actions, GitLab CI, or Jenkins — no AWS credentials needed.

GitHub Actions Example

name: JMeter AWS Load Test (LocalStack)

on:
  push:
    branches: [main, develop]
  pull_request:

jobs:
  load-test:
    runs-on: ubuntu-latest

    services:
      localstack:
        image: localstack/localstack:latest
        ports:
          - 4566:4566
        env:
          SERVICES: sqs,kinesis
          DEFAULT_REGION: us-east-1
        options: >-
          --health-cmd "curl -f http://localhost:4566/_localstack/health"
          --health-interval 10s
          --health-timeout 5s
          --health-retries 10

    steps:
      - name: Checkout code
        uses: actions/checkout@v3

      - name: Set up Java
        uses: actions/setup-java@v3
        with:
          java-version: '11'
          distribution: 'temurin'

      - name: Download JMeter
        run: |
          wget https://archive.apache.org/dist/jmeter/binaries/apache-jmeter-5.6.2.tgz
          tar -xzf apache-jmeter-5.6.2.tgz

      - name: Install AWS CLI Local
        run: pip install awscli-local

      - name: Wait for LocalStack
        run: |
          until curl -s http://localhost:4566/_localstack/health | grep '"sqs": "running"'; do
            echo "Waiting for LocalStack..."
            sleep 2
          done

      - name: Create AWS Resources
        run: |
          awslocal sqs create-queue --queue-name jmeter-local-queue
          awslocal kinesis create-stream \
            --stream-name jmeter-local-stream \
            --shard-count 2

      - name: Run JMeter Tests
        run: |
          ./apache-jmeter-5.6.2/bin/jmeter -n \
            -t tests/aws-localstack-test.jmx \
            -l results/results.jtl \
            -e -o results/html-report/ \
            -JAWS_ENDPOINT=http://localhost:4566 \
            -JAWS_ACCESS_KEY=test \
            -JAWS_SECRET_KEY=test \
            -JAWS_REGION=us-east-1

      - name: Upload JMeter Report
        uses: actions/upload-artifact@v3
        with:
          name: jmeter-html-report
          path: results/html-report/

      - name: Check Error Threshold
        run: |
          ERROR_RATE=$(grep -oP 'errorPct="\K[^"]+' results/results.jtl | tail -1)
          if (( $(echo "$ERROR_RATE > 1.0" | bc -l) )); then
            echo "❌ Error rate $ERROR_RATE% exceeds threshold!"
            exit 1
          fi
          echo "✅ Error rate $ERROR_RATE% is within threshold"

Step 9: Switching Between LocalStack and Real AWS

The cleanest approach is a JMeter property file per environment.

Create config/localstack.properties:

AWS_ENDPOINT=http://localhost:4566
AWS_ACCESS_KEY=test
AWS_SECRET_KEY=test
AWS_REGION=us-east-1
SQS_QUEUE_URL=http://localhost:4566/000000000000/jmeter-local-queue
KINESIS_STREAM=jmeter-local-stream

Create config/aws-staging.properties:

AWS_ENDPOINT=
AWS_ACCESS_KEY=AKIAIOSFODNN7EXAMPLE
AWS_SECRET_KEY=wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY
AWS_REGION=us-east-1
SQS_QUEUE_URL=https://sqs.us-east-1.amazonaws.com/123456789012/staging-queue
KINESIS_STREAM=staging-stream

Run with the desired environment:

# LocalStack
./bin/jmeter -n -t test.jmx -q config/localstack.properties

# Staging AWS
./bin/jmeter -n -t test.jmx -q config/aws-staging.properties

One test plan. Two environments. Zero code changes. ✅

Troubleshooting LocalStack

Connection Refused on Port 4566

# Check if LocalStack is running
docker ps | grep localstack

# Check LocalStack logs
docker logs localstack

Service Not Ready

# Wait for all services to be healthy
curl http://localhost:4566/_localstack/health | python3 -m json.tool

Messages Not Appearing

# Verify queue exists
awslocal sqs list-queues

# Check queue attributes
awslocal sqs get-queue-attributes \
  --queue-url http://localhost:4566/000000000000/jmeter-local-queue \
  --attribute-names All

Kinesis Stream Not Active

# Check stream status
awslocal kinesis describe-stream \
  --stream-name jmeter-local-stream

Plugin Can’t Connect to LocalStack

Make sure the plugin’s endpoint field is set — some plugins default to the real AWS endpoint and ignore system properties. Check the plugin’s documentation for the exact field name (Custom Endpoint, Endpoint URL, Service Endpoint).

LocalStack Free vs Pro

Feature	LocalStack Free	LocalStack Pro
SQS	✅ Full support	✅ Full support
Kinesis	✅ Basic support	✅ Enhanced support
Persistence	✅ Basic	✅ Advanced
CloudWatch Metrics	❌	✅
Multi-region	❌	✅
CI/CD integrations	✅	✅
Price	Free	Paid

For most JMeter testing use cases — including SQS and Kinesis — the free tier is more than enough.

Conclusion

LocalStack transforms your JMeter AWS testing workflow by:

💰 Eliminating AWS costs during development and CI/CD runs
⚡ Removing network latency for faster test iterations
🔒 Keeping test data local — no sensitive data leaves your machine
🔁 Enabling environment switching with a single property file
🤖 Powering CI/CD pipelines with zero cloud credentials

The recommended workflow is:

LocalStack (Dev/CI) → Real AWS Staging → Real AWS Production

Build and validate your JMeter test plans on LocalStack, run final load benchmarks on real AWS staging, and you’ll catch performance issues long before they reach production.
